Keysight / Agilent 6621A

Keysight / Agilent 6621A System Power Supply, 80W, 2 outputs

Keysight high performance DC power supplies offer spec and accuracy for test optimization. The multiple output, 4W - 105W GPIB 6621A - 6624A and 6627A provide dual-range outputs; fast, low-noise outputs; built-in measurements and advanced programmable features; and protection features to ensure DUT safety.

The Keysight 80W, dual-output 6621A is a versatile solution to help improve system accuracy and reduce test time in a 3U high package.

Output ratings

• Low-range volts, amps: 0 to 7 V, 0 to 10 A
• High range volts, amps: 0 to 20 V, 0 to 4 A

Programming accuracy at 25°C ±5°C

• Voltage: 0.06% + 19 mV
• Current: 0.16% + 100 mA

Ripple & noise (20 Hz to 20 MHz)

• Voltage rms: 500 µV, 500 µV
• Peak-to-peak: 3 mV, 3 mV
• Current rms: 1 mA, 1 mA
